Capanivo
Capacitance Level Switch for SOLIDS
Precise and reliable capacitive limit detection, constant even with varying material properties. Certified for hazardous locations (Dust Ex).
Capanivo
Our Solutions For
- Light materials
- Dusty environments
- Pneumatic filling
- Overpressure
- Very strong caking
- Corrosion resistance for aggressive material
- High process temperature
- High standard of safety requirement
- Explosive environments
Special Features
- Very high sensitivity (DK ≥ 1.6)
- Functionality independent of silo wall
- Range of process connections
- Adjustable switching delay
- Variety of mechanical versions
- Pipe and cable extension
- Overpressure up to 25 bar
- Temperature range from - 40 °C to +180 °C
- Food compliant version
Technical Data
- Housing Plastics PA 6 or Aluminum IP 66
- Certificates ATEX II 1/2D, TR-CU, IEC-Ex
- Process temperature – 40°C to + 180°C (– 40°F to + 356°F)
- Pressure – 1 .. +25 bar (– 14.5 .. + 363 psi)
- Sensitivity DK value ≥ 1,6
- Supply voltage 21.. 27V DC Relay SPDT; 21.. 230V AC/21..45V DC Relay DPDT 20.. 40V DC PNP
- Process connectionG 1", G 1½", NPT 1¼", NPT 1½"
- Material probe Plastics PPS, FDA listed, food grade material
- Material process connection Plastics PPS, 1.4305 (SS 303), aluminium
