Vibranivo
Vibrating Level Switch for SOLIDS & SEDIMENTS IN LIQUIDS
The universal unit for reliable level monitoring of granulated and powdered bulk goods – versatile, suitable especially for applications with high mechanical loading and measurement of bulk goods in liquids; certified for hazardous locations (gas and dust)
Vibranivo 2000/6000
Vibranivo 4000
Our Solutions For
- Extremely light product density
- Pneumatic filling
- Process overpressure
- Limited space
- Vibration within the vessel
- High reliability requirements
- High hygienic requirements
- Explosive environments
- Sediment levels in liquids
Special Features
- 2-wire instrument
- Very high sensitivity (< 5g/l - Vibrasil®)
- Surface roughness of 0.75 µm
- High quality material in the process (SS 316L)
- Cable and pipe (screwed) extension
- Suitable for overpressure up to 16 bar
- Temperature range from - 40 °C to +150 °C
- Extremely robust short version
- PFA and Teflon coating
- NAMUR Standard
- Level control of sediments in liquids
Technical Data
- VN Type 1000/5000
- Housing Aluminium IP66 / NEMA Type 4X
- Pressure range -1 up to +16 bar (-14.5 up to +145 psi)
- Supply voltage/ Relay SPDT 19..230V AC, 19..55V DC Signal output Relay DPDT 19..230V AC, 19..36V/55V DC PNP 18..50V DC 3-wire 2-wire without contact 19..230V AC/DC 8/16mA; 4-20mA 12,5-30/36V DC 2-wire
- Versions with ATEX II 1D and 1/2D certificates ATEX II 1G and 1/2G EEx ia IIC ATEX II 2G EEx de [ia] IIC, EEx d [ia] IIC FM Cl. I, II, III, Div.1 Gr. A-G; Zone 0 CSA Cl. I, II, III Div.1 Gr. A-G; Zone 0 TR-CU, IEC Ex
- Process -40°C up to +150°C temperature (-40°F up to + 302°F)
- Sensitivity From 50g/l (3lb/ft3) adjustable in 2 steps
- Process R 1½" conical; NPT 1½"; connection various flanges available
- Vibration fork/ Stainless steel 1.4301 (SS304) or 1.4404 (SS316L) extension [*]various lengths available
