Mononivo
Vibrating Level Switch for SOLIDS
The vibrating rod for reliable level detection for all bulk materials. Versatile and maintenance-free. Certified for hazardous locations
Mononivo
Our Solutions For
- Light products from 20 g/l
- Powdery material with strong caking properties
- Coarse-grained granulate
- Pneumatic filling
- Process overpressure
- Limited space
- verfill detection within pipes and shafts
- Vibration within the vessel
- High safety standard
- High hygienic requirements
- Explosive environments
Special Features
- Compact limit switch with threads from 1"
- Sensitivity adjustable in 4 settings
- High surface quality
- High quality material in the process (SS 316L)
- Heavy mechanical loading
- Robust version for overpressure up to 16 bar
- Temperature range from - 40 °C to +150 °C
- Pipe extension (screwed
Technical Data
- Mononivo 4000
- Housing Aluminium IP 67 / NEMA Type 4X
- Certificates ATEX II 1/2D Ex ta/tb IIIC T! Da/Db IP6X TR-CU Ex ta/tb IIIC T! Da/Db X
- Process temperature -40°C up to +150°C (-40°F up to +302°F)
- Pressure -1 up to +16 bar (-14.5 up to +232 psi)
- Sensitivity Adjustable in 4 settings: from 20g/l (1.25lb/ft3)
- Supply 19-230V AC, 19-40V DC relay, voltage 18-50V DC PNP 3-wire
- Process connection G 1"; G 1½" ; NPT 1"; NPT 1¼"; NPT 1½" Triclamp 2"; various flanges available
- Material extension Stainless steel 1.4301 (SS304) / 1.4541 (SS321) or 1.4404 (SS316L)
IEC-Ex ta/tb IIIC T! Da/Db IP6X
FM DIP Cl. II, III Div.1 Group E, F, G
